8mm Precision DC Geared Motor - iSky Motor Product Details 8mm Precision DC Geared Motor - Product Overview 8mm Precision DC Geared Motor - Product Overview 8mm Precision DC Geared Motor - Product Overview 8mm Precision DC Geared Motor - Product Overview 8mm Precision DC Geared Motor - Product Overview 8mm Precision DC Geared Motor - Product Overview 8mm Precision DC Geared Motor - Product Overview 8mm Precision DC Geared Motor - Product Overview 8mm Precision DC Geared Motor - Product Overview

SK-LP28BL-2487

  • High torque & High speed
  • PWM control & Low noise
  • Application：Coffee machine, Valve, Pump, Medical equipment, ATM,etc.
Diameter 28 mm
Voltage 6-24V DC
Speed 13-632 r/min
Torque 2-80 kg.cm
Noise Level ≤55 dB
Life time customizable
Request a Quote
Technical Drawings - 8mm DC Geared Motor Technical Drawings - 8mm DC Geared Motor Technical Drawings - 8mm DC Geared Motor Technical Drawings - 8mm DC Geared Motor Technical Drawings - 8mm DC Geared Motor Technical Drawings - 8mm DC Geared Motor Technical Drawings - 8mm DC Geared Motor Technical Drawings - 8mm DC Geared Motor Technical Drawings - 8mm DC Geared Motor Technical Drawings - 8mm DC Geared Motor

Dimensions

All dimensions are in (mm) unless otherwise noted. Drawings are for reference only—please contact us to confirm exact specifications.
Performance Specifications - 8mm DC Geared Motor Performance Specifications - 8mm DC Geared Motor Performance Specifications - 8mm DC Geared Motor Performance Specifications - 8mm DC Geared Motor Performance Specifications - 8mm DC Geared Motor

Parameters

Gearbox Stages 1 2 3 4 5
Gear Ratio 3.7 14 51 189 /
5.2 19 71 264 /
/ 27 100 369 /
/ / 139 515 /
/ / / 721 /
Gearbox Length L(mm) 27.5 35.7 43.9 52.1 /
Note: Performance curves show speed-torque characteristics at rated voltage. Custom performance specifications available upon request for specific applications.
Gearbox Motor Specifications Gearbox Motor Specifications Gearbox Motor Specifications Gearbox Motor Specifications Gearbox Motor Specifications

Performance Data

Gearbox Motor Model Voltage (V) No Load Max Efficiency Load
Current (A) Speed (r/min) Current (A) Speed (r/min) Torque (kg.cm)
SK-LP28-2847-24632 24 ≤0.45 632 ≤2.3 505 2.7
SK-LP28-2847-24444 24 ≤0.45 444 ≤2.3 355.6 3.8
SK-LP28-2847-24235 24 ≤0.45 235 ≤2.3 188 6.4
SK-LP28-2847-24169 24 ≤0.45 169 ≤2.3 135 9
SK-LP28-2847-24120 24 ≤0.45 120 ≤2.3 96 12
SK-LP28-2847-2463 24 ≤0.45 63 ≤2.3 50.8 21
SK-LP28-2847-2433 24 ≤0.45 33 ≤2.3 26 41
SK-LP28-2847-2417 24 ≤0.45 17 ≤2.3 13 73
Remarks:
1. The Performance of gear motor are for reference only. We can customize per your own unique requests.
2. Most of our Customization service are no need extra or new toolings.
3. This gear motor could be matched with Hall sensor encoder.
4. Output shaft could be customized per your drawings.
